Description
RIOT 400 TOURING
SHARE THE RIDE
With a versatile crossover sled with two-up seating, sharing the ride has never been easier. Bring a friend along for any adventure with the adaptable Riot Touring, previously known as the BLAST XR 4000 Touring.
146″/ 1.25″ |
Ripsaw |
Turn-Key Electric |
AMS |
Black/Woody’s Orange |
Track/Lug |
Track Type |
Starter |
Suspension |
Color |
LEARN MORE
POWERFUL AND RESPONSIVE
400-SERIES EFI ENGINE
A 397cc single-cylinder 2-stroke engine with 65-class horsepower and electronic fuel injection (EFI) offers quicker, more responsive power that gives you a smoother take off every time.
LEARN MORE
ELIMINATES BUMPY RIDES
SLIDE-RAIL REAR SUSPENSION
The responsive rear suspension uses a full 12.5 inches of travel to absorb any bumps on the trail. With support like this, every ride will be so stable and smooth that you won’t even notice the rough snow.
ENHANCED MANEUVERABILITY
MID-SIZED CHASSIS
Nothing beats a snowmobile that’s easy to handle. With its lightweight, mid-sized chassis, the BLAST XR Touring gives you more control over your ride, no matter how challenging the conditions.
EXTRA SUPPORT
OVERLOAD SPRINGS
Dual overload springs increase the sled’s carrying capacity, providing the extra support needed for a second rider so you can share the ride with confidence.
BRING A FRIEND
2-UP SEATING
Designed to comfortably seat two, the BLAST XR Touring is built to bring a friend along for every adventure.
READY TO GO
TURN-KEY ELECTRIC START
The Riot 400 Touring comes with a convenient turn-key electric start and magnetic tether switch that will stop the engine if disconnected, offering a quick start and additional safety.
EASILY ACCESS INFORMATION
POWERSPORT GAUGE
All you need to know is now in one place. Be fully aware of everything going on with your vehicle with this easy-to-read, digital display.
ENGINE
|
RIOT 400 TOURING |
Engine Type |
400, 2-Stroke |
Displacement (cc) |
397cc |
Cooling |
Liquid |
Cylinders |
1 |
Bore x Stroke (mm) |
85 x 70 mm |
Lubrication |
Electronic Injection |
Ignition |
Digitally Controlled CDI |
Engine Starter Output |
270 W @ 3000 RPM |
Fuel Delivery |
Electronic Fuel Injected (EFI) |
Exhaust |
APV w/ Tuned Pipe, Pipe Sensor, Manifold and Stainless Steel Muffler |
Fuel Capacity |
11.7 gal. |
Oil System Capacity |
3.25 qt. |
Coolant System Capacity |
5.0 qt. |
Minimum Octane |
91 |
POWERTRAIN
|
RIOT 400 TOURING |
Drive Clutch |
CVTech Trailbloc |
Driven Clutch |
CVTech Invance |
Drive System |
Arctic Drive System |
Brakes |
Stealth Hydraulic Master Cylinder w/ Lightweight Caliper |
Clutch Calibration |
0-5,000 ft. |
Gearing |
19/50 |
Chain Pitch |
90 |
Track Drive Sprocket |
8 Tooth, 2.86 Pitch, Involute |
Reverse |
Push-Button Engine |
SUSPENSION
|
RIOT 400 TOURING |
Front Suspension |
Arctic Mountain Suspension (AMS) |
Ski Shocks |
Hydraulic Twin Tube |
Sway Bar |
Standard |
Front Travel |
7.2 in. |
Rear Suspension |
Slide-rail, dual shock, adjustable torsion springs and overload springs |
Front Track Shock |
Hydraulic Twin Tube |
Rear Track Shock |
Hydraulic Twin Tube |
Rear Travel |
12.5 in. |
DIMENSIONS
|
RIOT 400 TOURING |
Overall Chassis Length |
128 in. |
Overall Chassis Width |
46-47 in. |
Overall Chassis Height |
51 in. |
Track Type |
Ripsaw |
Track Width |
15 in. |
Track Length |
146 in. |
Lug |
1.25 in. |
Pitch |
2.86 in. |
Ski Stance |
39.5-40.5 in. Adjustable |
Ski Type/Width |
Trail – 6 in. |
Runner Type |
Twin Split |
INSTRUMENTATION
|
RIOT 400 TOURING |
Type of Gauge |
Powersport |
Speedometer |
Digital |
Tachometer |
Digital |
Odometer |
Digital |
Fuel |
Digital |
Oil |
Indicator Light |
Coolant |
Indicator Light |
Clock |
N/A |
Battery Voltage |
N/A |
Altimeter |
N/A |
Hours |
Digital |
FEATURES
|
RIOT 400 TOURING |
Color |
Black/Woody’s Orange |
Heat Exchanger |
Front/Long Tunnel |
Starter |
Turnkey Electric Start |
Handlebars |
Hooked |
Lighting |
Halogen 1-Bulb |
Seating |
Mountain |
Standard Accessories |
Hand & Thumb Warmers, Standard Brake Disc, Standard Steering, Passenger Seat, Tether Switch |
Windshield |
15.5 in High Height |
*Vehicle specifications are subject to change.
